Pramet 160C08R-S57PN13 6761674 Shell Milling Cutter - Heavy Duty
MODEL 6761674
$1,296.59 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $1
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
Axial rake angle (GAMP)
-4
Clamping Type Code (MTP)
Screw clamping through hole
Connection diameter - inch (DCON MS)
1.575
Connection diameter - millimeter (DCON MS)
40
Cutting diameter - inch (DC)
6.299
Cutting diameter - millimeter (DC)
160
Cutting diameter maximum - inch (DCX)
6.921
Cutting diameter maximum - millimeter (DCX)
175.8
Functional length - millimeter (LF)
63
Hand (Cutting direction)
Right
Insert index count (NOI)
8
Keyway depth - millimeter (KWD)
9
Keyway width - millimeter (KWW)
16.4
Peripheral effective cutting edge count (ZEFP)
8
Radial rake angle (GAMF)
-6
Rotational speed maximum (RPMX)
2700
Shank
Shell mill DIN 8030 C
Face mill with double negative geometry which utilises 8 off PNMU 1308DN.. or PNMQ 1308DN.. double-sided inserts, cutting diameter 160 to maximum 175.8mm with 57° approach angle and 40mm connection bore according to DIN 8030-C, 63mm protrusion length for face milling with a maximum depth of cut of 10.0mm
