Red Lion Sixnet E2-16DO24-D ETrak2 distributed I/O module with 16 digital output channels at 24V DC. Designed for industrial automation and remote monitoring, this module provides reliable discrete output control in a compact form factor. Part of the Sixnet ETrak2 family, it supports distributed I/O architectures for SCADA and process control systems.

Discrete Output Channels

• Output voltage range 10-30 VDC
• Max. output power: 1A Per channel, 16A per module, .8A at 60°C 8 channels at 24 VDC
• Max. off state leakage: 0.01 mA (less than 10 uA)
• Short circuit protection: self-reset fuses (trip above 1.5 Amp)
• Min. load: 1 mA
• Inrush current: 5 Amps (100 ms surge)
• Typical on resistance: 0.3 Ohms (Drop 0.3 VDC @ 1 Amp)
• Input isolation: 150 Volts (16 channel modules only)
• All channels Scan rate: 1 ms

Environmental

• Operating temperature: -40 to 75°C
• MTBF: 1,488,653 Hours GB @ 40°C per MIL-HNDBK-217F2

​​Configuration

• Configured using Sixnet I/O Tool Kit
• Graphical User Interface (GUI)
