Red Lion Controls E2-16AI20M-D ETRAK2 mod16AI20mAE2BASE1
MODEL E2-16AI20M-D
Contact supplier for technical support on: 717 767 6511 x2
$1,199.00 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: See conditions
Specifications:
Analog Input Channels
- Analog Input Range: 4-20 mA
- A/D resolution: 16 bits (0.003%), 10 bits (fast option, Channels 1 and 2 only)
- Full scale accuracy +/- 0.02% (at 20 °C, 16 bit mode)
- Temperature coefficient +/- 50 ppm per °C (span and offset)
- Input impedance (resistance): 100 ohms
- Protection: Self-resetting short circuit protection fuses
- DMRR (differential mode) 66 db at 50/60 Hz
- Fastest update time [# of chan.]: 880 ms [all] -16-bit; 145 ms [all] -14-bit; 1 ms [2] -10-bit
Environmental
| Operating temperature | -40 to 75°C |
|---|---|
| MTBF | 1, 575, 530 Hours GB @ 40°C per MIL-HNDBK-217F2 |
Configuration
- Configured using Sixnet I/O Tool Kit
- Graphical User Interface (GUI)
