Red Lion Sixnet E2-32AI10V-D ETrak2 distributed I/O module with 32 analog input channels, 10 VDC input range, and AIE2 base. Designed for DIN-rail mounting in industrial automation and remote monitoring applications, it integrates with Sixnet ETrak2 systems for flexible data acquisition.

Analog Input Channels

• Analog Input Range: 0 to +10 VDC
• A/D resolution 16 bits (0.003%)
• Full scale accuracy +/- 0.02% (at 20 °C, 16 bit mode)
• Temperature coefficient +/- 50 ppm per °C (span and offset)
• Input impedance (resistance): 200 Kohms
• DMRR (differential mode) 66 db at 50/60 Hz
• Fastest update time [# of chan.]: 880 ms [all] -16-bit; 145 ms [all] -14-bit; 1 ms [2] -10-bit

Environmental

• Operating temperature: -40 to 75°C
• MTBF: 1,151,881 Hours GB @ 40°C per MIL-HNDBK-217F2

​​Configuration

• Configured using Sixnet I/O Tool Kit
• Graphical User Interface (GUI)
