Red Lion Controls E2-16ISOTC-D ETRAK2 16INS AI E2BASETC1
MODEL E2-16ISOTC-D
Contact supplier for technical support on: 717 767 6511 x2
$1,803.00 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: See conditions
Specifications:
Analog Input Channels
- Analog Input Ranges: +/-250 mV, Thermocouples supported J, K, E, R, T, B, L, N & S
- A/D resolution 16 bits (0.003%)
- Full scale accuracy +/- 0.02% (at 20 °C, 16 bit mode)
- Temperature coefficient +/- 50 ppm per °C (span and offset)
- Input impedance (resistance): 200 Kohms
- DMRR (differential mode) 66 db at 50/60 Hz
- Fastest update time (all 16 channels): 200 ms
- Accuracy typical uncalibrated +/- 0.5 °C
- Common mode input voltage:
- Between two input terminals +/- 60VDC
- Between inputs and ground 300 volts
Configuration
- Configured using Sixnet I/O Tool Kit
- Graphical User Interface (GUI)
