FAG 52232MP Double Direction Thrust Ball Bearing
MODEL 52232MP
$5,374.81 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable:No
B
20 mm
Current
2A
D
225 mm
d
140 mm
D 1
163 mm
d a max
160 mm
D a max
186 mm
I.D.
6 2/7 in
Limiting speed
1900 1/min n G
Mass
12, 2 kg m
Minimum load factor
3, 2 A
Product Type
Ball Thrust Bearings
r 1 min
1, 1 mm
r a max
1, 5 mm
r a1 max
1 mm
r min
1, 5 mm
T 2
90 mm
Specifications
| d | 140 mm |
| D | 225 mm |
| T 2 | 90 mm |
| B | 20 mm |
| D 1 | 163 mm |
| D a max | 186 mm |
| d a max | 160 mm |
| r 1 min | 1, 1 mm |
| r a max | 1, 5 mm |
| r a1 max | 1 mm |
| r min | 1, 5 mm |
| Mass | 12, 2 kg | m |
|---|---|---|
| Basic dynamic load rating, axial | 240000 N | C a |
| Basic static load rating, axial | 765000 N | C 0a |
| Minimum load factor | 3, 2 | A |
| Limiting speed | 1900 1/min | n G |
| Fatigue limit load, axial | 24700 N | C ua |
