Image for Illustration purposes only. Actual product may vary

View in markdown

Pramet A16T-SCLCR 3 boring bar — ISO S, right hand, 12 in functional length, 1.201 in minimum bore diameter, 1 in connection diameter, 0.906 in shank height, 95° tool cutting edge angle, screw clamping through hole, for CC.. inserts. Article 6788485.

MODEL 6788485

BRAND

Pramet

SKU

6059348

WEIGHT

1.539 lb

UOM

each

$204.12 Each

Prices are subject to change

FREE SHIPPING ON ORDERS OVER $100

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Returnable: Yes

Clamping Type Code (MTP)

Screw clamping through hole

Connection diameter - inch (DCON MS)

1

Connection diameter - millimeter (DCON MS)

25.4

Functional length - inch (LF)

12

Functional width - inch (WF)

0.64

Inclination angle (LAMS)

-4

Minimum bore diameter - inch (DMIN)

1.201

Ortogonal rake angle (GAMO)

0

Shank height - inch (H)

0.906

Screw clamp boring bar for holding a 80° rhombus positive insert with an inscribed circle diameter of 3/8'', 5/32'' thick (ANSI designation CC.. 32.5. ), right hand 95° side and end cutting with off-set shank, steel with coolant hole, 1'' diameter x 12'' long for taper boring and longitudinal boring with and without shoulder

When will I be charged for my order? Ordering Do you provide credit terms? Ordering Can I get a discounted price? I am a reseller / government entity. Ordering What is the return/warranty policy? Ordering Can it be shipped today? Ordering Does “Usually ships in 24 hours” mean it’s in stock? Ordering Read full FAQ All FAQs
Line Drawing PNG
