Pramet REHT 1604M0SN-M:M8310 6931665 Milling Insert - Copy And Profile
MODEL 6931665
This product has a minimum order quantity of (10 minimum) This is the minimum order quantity available when purchasing this product.
$15.78 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity(10 minimum)
Typically Ships in: 1 day
Returnable: Yes
Chipbreaker
M
Coating
M8310
Coating process
PVD
Coating property (CTP)
1
Cooling effect
Slightly negative effect on tool life
Depth of cut maximum - inch (APMX)
0.157
Depth of cut maximum - millimeter (APMX)
4
Depth of cut minimum - inch (APMN)
0.02
Depth of cut minimum - millimeter (APMN)
0.5
Feed maximal - millimeter
0.35
Feed minimal - millimeter
0.08
Feed_MAX_IMP_NUM
0.014
Feed_MIN_IMP_NUM
0.003
Fixing hole diameter - inch (D1)
0.217
Fixing hole diameter - millimeter (D1)
5.5
Insert diameter - inch (INSD)
0.63
Insert diameter - millimeter (INSD)
16
Insert shape code (SC)
R - round
Insert thickness - inch (S)
0.187
Insert thickness - millimeter (S)
4.76
Single-sided milling insert REHT 1604 with chip-breakers, round for a maximum depth of cut of 4.0mm, with an indexing accuracy according to ISO-tolerance class-H and M geometry with rounded cutting edges and facet, M8310 PVD coated fine grained WC-Co carbide within ISO-grade range P01-P10 for machining of steel with face mills SOE06Z
