Pramet 100J2R197W100-ISAD11E150 helical end milling cutter, square shoulder, 1 in cutting diameter, 1.496 in maximum depth of cut, 8 inserts, 2 flutes, Weldon shank DIN 1835B, right hand, through coolant. Article 6790020.

MODEL 6790020

BRAND

Pramet

SKU

6063931

WEIGHT

0.659 lb

UOM

each

$788.65 Each

Prices are subject to change

FREE SHIPPING ON ORDERS OVER $100

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Returnable: Yes

Axial rake angle (GAMP)

5

Clamping Type Code (MTP)

Screw clamping through hole

Connection diameter - inch (DCON MS)

1

Connection diameter - millimeter (DCON MS)

25.4

Coolant supply property (CSP)

1

Cutting diameter - inch (DC)

1

Cutting diameter - millimeter (DC)

25.4

Depth of cut maximum - inch (APMX)

1.496

Flute count (NOF)

2

Hand (Cutting direction)

Right

Overall length - inch (OAL)

4.508

Overall length - millimeter (OAL)

115

Peripheral effective cutting edge count (ZEFP)

8

Radial rake angle (GAMF)

-10.5

Rotational speed maximum (RPMX)

24100

Shank

Weldon shank DIN 1835B

Usable Length - inch (LU)

1.969

Shoulder mill with positve/negative geometry which utilises 8 off ADMX 11T3.. or ADEX 11T3.. single-sided inserts, cutting diameter 1.000'' with 90° approach angle and 1.000'' Weldon shank according to DIN 1835B, 1.496'' functional and 4.508'' overall length, through coolant for copy milling, shallow shoulder milling, shallow slot milling, ramping, helical milling, plunge milling and progressive plunge milling

When will I be charged for my order? Ordering Do you provide credit terms? Ordering Can I get a discounted price? I am a reseller / government entity. Ordering What is the return/warranty policy? Ordering Can it be shipped today? Ordering Does “Usually ships in 24 hours” mean it’s in stock? Ordering Read full FAQ All FAQs
Line Drawing PNG
