Pramet 25E2R080B25-SZD09-C high-feed end milling cutter body, 0.457 in cutting diameter, 0.039 in maximum depth of cut, 2-insert SZD09 design, Weldon shank DIN 1835B, 25 mm connection diameter, 140 mm overall length, through coolant, right-hand, for face milling in cast iron and hardened materials. Article 6759694.

Axial rake angle (GAMP)

10

Clamping Type Code (MTP)

Screw clamping through hole

Connection diameter - inch (DCON MS)

0.984

Connection diameter - millimeter (DCON MS)

25

Coolant supply property (CSP)

1

Cutting diameter - inch (DC)

0.457

Cutting diameter - millimeter (DC)

11.6

Cutting diameter maximum - inch (DCX)

0.984

Cutting diameter maximum - millimeter (DCX)

25

Hand (Cutting direction)

Right

Insert index count (NOI)

2

Overall length - inch (OAL)

5.512

Overall length - millimeter (OAL)

140

Peripheral effective cutting edge count (ZEFP)

2

Radial rake angle (GAMF)

-6

Rotational speed maximum (RPMX)

22800

Shank

Weldon shank DIN 1835B

Usable Length - millimeter (LU)

80
