Image for Illustration purposes only. Actual product may vary

View in markdown

Pramet 63J6R110H50-CSD12X66 helical end milling cutter, square shoulder, 2.48 in (63 mm) cutting diameter, 6 flutes, 36 inserts, 90° cutting edge angle, 2.587 in maximum depth of cut, 4.3307 in functional length, 8.335 in overall length, arbor DIN 69871-1, right hand, top clamping, internal coolant. Article 6761744.

MODEL 6761744

BRAND

Pramet

SKU

6064804

WEIGHT

10.803 lb

UOM

each

$2,541.77 Each

Prices are subject to change

FREE SHIPPING ON ORDERS OVER $100

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Returnable: Yes

Axial rake angle (GAMP)

8

Clamping Type Code (MTP)

Top clamping

Connection size code machine side (CZC MS)

50

Cooling (CSP)

1

Cutting diameter - inch (DC)

2.48

Cutting diameter - millimeter (DC)

63

Depth of cut maximum - millimeter (APMX)

65.7

Flute count (NOF)

6

Functional length - millimeter (LF)

110

Hand (Cutting direction)

Right

Insert index count (NOI)

36

Overall length - inch (OAL)

8.335

Overall length - millimeter (OAL)

211.7

Peripheral effective cutting edge count (ZEFP)

36

Radial rake angle (GAMF)

-5

Rotational speed maximum (RPMX)

2500

Shank

Arbor DIN 69871-1

Usable Length - millimeter (LU)

90

Shoulder mill with extended flute with positve/negative geometry which utilises 36 off SDGX 1205.. or SDMX 1205.. single-sided inserts, cutting diameter 63mm with 90° approach angle and SK 50 taper shank according to ISO/DIS 7388-1, 90mm functional and 211.7mm overall length for deep shoulder milling and deep slot milling with a maximum depth of cut of 65,7mm

When will I be charged for my order? Ordering Do you provide credit terms? Ordering Can I get a discounted price? I am a reseller / government entity. Ordering What is the return/warranty policy? Ordering Can it be shipped today? Ordering Does “Usually ships in 24 hours” mean it’s in stock? Ordering Read full FAQ All FAQs
Line Drawing PNG
