Dormer Pramet A1081.2 (MID 5968338) is a 1.2mm (0.0472") jobber length drill with a 135° split point, Steam Tempered finish, and High Speed Steel (HSS) construction. It meets DIN 338 standards and features a Quick Spiral flute geometry for efficient chip evacuation in stainless steel and high-temperature alloys. Overall length is 38mm with a 16mm flute length.
MODEL 5968338
This product has a minimum order quantity of (10 minimum) This is the minimum order quantity available when purchasing this product.
$6.60 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity(10 minimum)
Typically Ships in: 1 day
Returnable: Yes
ApplicationAngleIcon_DICT_SEL
Drill point 135°
Basic Standard
DIN 338
Coating
Steam Tempered
Connection (shank) description
Cylindrical shank
Connection diameter - millimeter (DCON MS)
1.2
Cutting diameter - inch (DC)
0.0472
Cutting diameter - millimeter (DC)
1.2
Cutting diameter tolerance class (TCDC)
h8
Drill Length
Jobber
EDP number
7563
Hand (Cutting direction)
Right
Length chip flute - inch (LCF)
0.6299
Length chip flute - millimeter (LCF)
16
Material
HSS
Material application
M - Stainless steel, S - High-temperature alloys
MID number
5968338
Ordering code ANSI
A1081.2
Overall length - inch (OAL)
1.4961
Overall length - millimeter (OAL)
38
Point Angle (SIG)
135
Spiral form
Quick Spiral
Surface treatement
Steam Tempered
Usable length (ULDR)
4
The A108 drill from Dormer Pramet is sold in both fractional and metric diameters.
It is particularly suited for drilling stainless steels but can be used in many different machine and hand held applications.
It has a 135 degree split point which helps to self-center the drill and reduces the amount of force needed to drill the hole, whilst the steam oxide finish helps stop work piece material from sticking to the cutting edge of the drill.
The patented silver ring on the Dormer A108 drill on the larger sizes gives you confidence this is a genuine Dormer drill and also makes it very easy to find and read the drill size.
Another great Dormer branded drill.
*Note: split point tip not available below 1.6mm
