Dormer B1001 5986230 Hand Reamer 8FL 1 inch
MODEL 5986230
$213.87 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
Achievable hole tolerance (TCHA)
H7
Basic Standard
DIN 206
Clamping width - inch
0.7874
Clamping width - millimeter (WSC)
20
Coating
Bright/ST
Connection diameter - inch (DCON MS)
1
Connection diameter - millimeter (DCON MS)
25.4
Cutting diameter - fractional inch (DC)
1"
Cutting diameter - inch (DC)
1
Cutting diameter - millimeter (DC)
25.4
EDP number
179970
Flute count (NOF)
8
Hand (Cutting direction)
Right
Length chip flute - millimeter (LCF)
115
Material
HSS
Material application
K - Cast iron, N - Non-ferrous metals, P - Steel and cast steel
MID number
5986230
Ordering code ANSI
B1001
Overall length - inch (OAL)
9.0945
Overall length - millimeter (OAL)
231
Shank
Cylindrical shank with Square
Shank Diameter - millimeter
25.4
Hand reamer with left hand slow spiral flutes and a square drive, diameter 25.40mm (1") with an overall length of 231mm, a flute length of 115mm and 29mm long taper lead, according to DIN 206 standard for reaming precise holes within H7 tolerance, HSS with bright-steam tempered finish for machining free machining and plain carbon steel, grey and ductile cast-iron, wrought and cast aluminium and copper or copper alloys.
