Dormer B1227/8 5986467 Machine Reamer 7/8" 5F...

$183.56 Each Prices subject to change

5986467

Image for Illustration purposes only. Actual product may vary

View in markdown

Dormer B1227/8 5986467 machine reamer, 7/8 inch cutting diameter, 5 left hand helical flutes, High Speed Steel (HSS), ANSI standard. Bronze straight car reamer for non-ferrous metals and steel/cast steel. 1/2 inch connection diameter.

MODEL 5986467

BRAND

SKU

6076031

WEIGHT

0.617 lb

UOM

each

$183.56 Each

Prices are subject to change

FREE SHIPPING ON ORDERS OVER $100

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Returnable: Yes

Basic Standard

ANSI

Coating

ST/Bronze

Connection diameter - fractional inch (DCON MS)

1/2

Connection diameter - inch (DCON MS)

0.5

Connection diameter - millimeter (DCON MS)

12.7

Cutting diameter - fractional inch (DC)

7/8

Cutting diameter - inch (DC)

0.875

Cutting diameter - millimeter (DC)

22.23

EDP number

252420

Flute count (NOF)

5

Hand (Cutting direction)

Right

Length chip flute - fractional inch (LCF)

4.1/2

Length chip flute - inch (LCF)

4.5

Material

HSS

Material application

N - Non-ferrous metals, P - Steel and cast steel

MID number

5986467

Ordering code ANSI

B1227/8

Overall length - fractional inch (OAL)

6.7/8

Overall length - inch (OAL)

6.875

Overall length - millimeter (OAL)

174.63

Shank

Cylindrical shank

Car reamer with left hand slow spiral flutes and a reduced Tri-flats shank, nominal diameter 0.8750" (7/8") with an overall length of 6.7/8", a flute length of 4.1/2" and 3.7/8" starting taper, according to ANSI standard for enlarging holes or correcting misalignments, HSS with steam tempered-bronze finish for machining free machining and plain carbon steel, copper or copper alloys.

When will I be charged for my order? Ordering Do you provide credit terms? Ordering Can I get a discounted price? I am a reseller / government entity. Ordering What is the return/warranty policy? Ordering Can it be shipped today? Ordering Does “Usually ships in 24 hours” mean it’s in stock? Ordering Read full FAQ All FAQs

5.0 out of 5 · 3 reviews

Excelente tiempo de entrega

Verified · SKU 6080992

Rapido tiempo de entrega Read more

Herramientas dormer

Verified · SKU 6075840

EXCELENTE PROVEEDOR ME GUSTA SU ATENCION Y PRESENTAN EXCELENTES PRECIOS Read more

End mill dormer hss

Verified · SKU 6077311

Excelente herramienta de mecanizado , buena calidad para corte de acero inoxidables y al carbono Read more

Line Drawing PNG
