Image for Illustration purposes only. Actual product may vary
Dormer C16716.0 5984422 End Mill 16.00 mm
MODEL 5984422
$199.27 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
DORMER
Coating
Bright
Connection diameter - inch (DCON MS)
0.6299
Connection diameter - millimeter (DCON MS)
16
Cut length
Short
Cutting diameter - inch (DC)
0.6299
Cutting diameter - millimeter (DC)
16
Cutting diameter tolerance class (TCDC)
js14
Depth of cut maximum - inch (APMX)
1.2598
Depth of cut maximum - millimeter (APMX)
32
EDP number
59906
Flute count (NOF)
2
Flute helix angle (FHA)
30
Material
HSS-E
Material application
N - Non-ferrous metals, P - Steel and cast steel
MID number
5984422
Mill Profile
N - General Purpose Cutter Type for Low to High Resistance Materials
Ordering code ANSI
C16716.0
Overall length - inch (OAL)
7.874
Overall length - millimeter (OAL)
200
Peripheral effective cutting edge count (ZEFP)
2
Radial rake angle (GAMF)
12
Shank
Cylindrical shank DIN 1835A
C167 2 flute milling cutters have a short 2 flute design which gives high rigidity for increased strength and reduced vibration.
With extra-long reach for machining deep pockets in difficult to reach areas, they can be used for plunging, ramping and profile milling stainless steels, cast iron and steels.
C167 milling cutters are manufactured from High Speed cobalt which provides longer tool life and better performance.
The bright finish prevents workpiece material from sticking to the cutting edge so you get a cleaner, more accurate result
