Image for Illustration purposes only. Actual product may vary
Dormer C6181/8 7648008 End Mill ANSI 4FL 1/8 inch
MODEL 7648008
$36.68 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
ANSI
Coating
Bright
Connection diameter - fractional inch (DCON MS)
3/8
Connection diameter - inch (DCON MS)
0.375
Connection diameter - millimeter (DCON MS)
9.53
Cut length
Medium
Cutting diameter - fractional inch (DC)
1/8
Cutting diameter - inch (DC)
0.125
Cutting diameter - millimeter (DC)
3.18
Cutting diameter tolerance class (TCDC)
ANSI +.003/-.000
Depth of cut maximum - fractional inch (APMX)
3/8
EDP number
7648008
Flute count (NOF)
4
Flute helix angle (FHA)
30
Material
HSS-E
Material application
N - Non-ferrous metals, P - Steel and cast steel, S - High-temperature alloys
MID number
7648008
Mill Profile
N - General Purpose Cutter Type for Low to High Resistance Materials
Ordering code ANSI
C6181/8
Overall length - fractional inch (OAL)
2.5/16
Overall length - inch (OAL)
2.3125
Overall length - millimeter (OAL)
58.74
Radial rake angle (GAMF)
10
Shank
Cylindrical shank
C618 4-flute end mills from Dormer are very versatile and can be used for ramping and profile milling in steels, stainless steels and cast iron.
With a 30 degree helix to reduce vibration and improve performance when used in CNC machines, the tools are manufactured from premium High Speed cobalt, which provides excellent wear resistance, tool strength and performance.
With a bright finish to prevent workpiece material from sticking to the cutting surfaces of the tools, you can be certain of a clean and accurate result.
C618 4-flute end mills have a regular flute length to give you the rigidity needed for profile milling
