Image for Illustration purposes only. Actual product may vary

Dormer C3676.0 5984041 slot drill, 6mm cutting diameter, 3-flute, powder metallurgy cobalt HSS (HSS-E-PM), 40° helix, DIN 327 D. For stainless steel, non-ferrous metals, and steel/cast steel. 6mm shank, h6 tolerance, 8mm max depth of cut.

Name: Dormer C3676.0 5984041 slot drill, 6mm cutting diameter, 3-flute, powder metallurgy cobalt HSS (HSS-E-PM), 40° helix, DIN 327 D. For stainless steel,
Brand: Dormer Pramet
Price: 43.93 USD
Availability: InStock
Rating: 5.0 (3 reviews)

MODEL 5984041

BRAND

Dormer Pramet

SKU

6077683

WEIGHT

0.031 lb

UOM

each

$43.93 Each

Prices are subject to change

FREE SHIPPING ON ORDERS OVER $100

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Returnable: Yes

Basic Standard

DIN 327 D

Coating

ALCRONA

Coating property (CTP)

Connection diameter - inch (DCON MS)

0.2362

Connection diameter - millimeter (DCON MS)

Connection diameter tolerance machine side (TCDCONMS)

Cut length

Extra short

Cutting diameter - inch (DC)

0.2362

Cutting diameter - millimeter (DC)

Cutting diameter tolerance class (TCDC)

Depth of cut maximum - inch (APMX)

0.315

Depth of cut maximum - millimeter (APMX)

EDP number

355381

Flute count (NOF)

Flute helix angle (FHA)

Material

HSS-E-PM

Material application

M - Stainless steel, N - Non-ferrous metals, P - Steel and cast steel

MID number

5984041

Mill Profile

N - General Purpose Cutter Type for Low to High Resistance Materials

Ordering code ANSI

C3676.0

Overall length - inch (OAL)

2.0472

Overall length - millimeter (OAL)

Peripheral effective cutting edge count (ZEFP)

Radial rake angle (GAMF)

Shank

Weldon shank DIN 1835B

C367 3-flute milling cutters can be used for plunging, ramping and profile milling in steels, cast iron and stainless steels, making them very versatile.

With a 40 degree helix, they are designed for high performance when machining heat resistant materials on CNC machines and have an accurate diameter, making it possible to mill standard keyway slots to a P9 tolerance.

C367 milling cutters are manufactured from powder metal High Speed cobalt for greatly improved performance with longer tool life, whilst the Alcrona coating further increases the life of the tool and improves performance when milling materials which are difficult to machine
