Dormer S1394.5 7648874 square end mill, 4.50 mm cutting diameter, solid carbide, 4-flute, 30° helix angle, for K/M/N/P materials. 14 mm max depth of cut. DORMER standard.

Basic Standard

DORMER

Coating

Bright

Connection diameter - inch (DCON MS)

0.1969

Connection diameter - millimeter (DCON MS)

5

Corner radius - inch (RE)

0.089

Corner radius - millimeter (RE)

2.25

Cut length

Medium

Cutting diameter - inch (DC)

0.1772

Cutting diameter - millimeter (DC)

4.5

Cutting diameter tolerance class (TCDC)

ANSI +.000/-.002

Depth of cut maximum - inch (APMX)

0.5512

Depth of cut maximum - millimeter (APMX)

14

EDP number

7648874

Flute count (NOF)

4

Flute helix angle (FHA)

30

Material

HM

Material application

K - Cast iron, M - Stainless steel, N - Non-ferrous metals, P - Steel and cast steel

MID number

7648874

Mill Profile

N - General Purpose Cutter Type for Low to High Resistance Materials

Ordering code ANSI

S1394.5

Overall length - inch (OAL)

1.9685

Overall length - millimeter (OAL)

50

Peripheral effective cutting edge count (ZEFP)

4

Radial rake angle (GAMF)

10

Shank

Cylindrical shank
