Dormer S2333.0XD6 6706556 square end mill, 3.00mm cutting diameter, 2-flute, solid carbide (HM), 30° helix angle, 5mm max depth of cut. Suitable for stainless steel, steel/cast steel, and high-temperature alloys. DORMER standard.

Basic Standard

DORMER

Coating

TiSiN

Coating property (CTP)

1

Connection diameter - inch (DCON MS)

0.2362

Connection diameter - millimeter (DCON MS)

6

Corner radius - inch (RE)

0.0591

Corner radius - millimeter (RE)

1.5

Cut length

Extra short

Cutting diameter - inch (DC)

0.1181

Cutting diameter - millimeter (DC)

3

Cutting diameter tolerance class (TCDC)

h9

Depth of cut maximum - inch (APMX)

0.1969

Depth of cut maximum - millimeter (APMX)

5

EDP number

46706556

Flute count (NOF)

2

Flute helix angle (FHA)

30

Material

HM

Material application

M - Stainless steel, P - Steel and cast steel, S - High-temperature alloys

MID number

6706556

Mill Profile

N - General Purpose Cutter Type for Low to High Resistance Materials

Neck diameter - inch (DN)

0.1102

Neck diameter - millimeter (DN)

2.8

Ordering code ANSI

S2333.0XD6

Overall length - inch (OAL)

3.937

Overall length - millimeter (OAL)

100

Peripheral effective cutting edge count (ZEFP)

2

Radial rake angle (GAMF)

3

Shank

Cylindrical shank DIN 6535 HA

Usable Length - millimeter (LU)

30
