Dormer S23912.0 7648885 square end mill, 12.00 mm cutting diameter, solid carbide (HM), 4-flute, 30° helix angle, 25 mm max depth of cut. Suitable for K (cast iron), M (stainless steel), and P (steel/cast steel) materials. DORMER standard.

Basic Standard

DORMER

Coating

TiAlN

Coating property (CTP)

1

Connection diameter - inch (DCON MS)

0.4724

Connection diameter - millimeter (DCON MS)

12

Corner radius - inch (RE)

0.236

Corner radius - millimeter (RE)

6

Cut length

Medium

Cutting diameter - inch (DC)

0.4724

Cutting diameter - millimeter (DC)

12

Cutting diameter tolerance class (TCDC)

ANSI +.000/-.002

Depth of cut maximum - inch (APMX)

0.9843

Depth of cut maximum - millimeter (APMX)

25

EDP number

7648885

Flute count (NOF)

4

Flute helix angle (FHA)

30

Material

HM

Material application

K - Cast iron, M - Stainless steel, P - Steel and cast steel

MID number

7648885

Mill Profile

N - General Purpose Cutter Type for Low to High Resistance Materials

Ordering code ANSI

S23912.0

Overall length - inch (OAL)

2.9528

Overall length - millimeter (OAL)

75

Peripheral effective cutting edge count (ZEFP)

4

Radial rake angle (GAMF)

10

Shank

Cylindrical shank
