Dormer S2471/8 7648901 square end mill, 1/8" cutting diameter, 4-flute, solid carbide (HM), 30° helix angle. Suitable for machining steel, stainless steel, and cast iron (P, M, K). DORMER standard.

Basic Standard

DORMER"

Coating

TiAlN

Coating property (CTP)

1

Connection diameter - fractional inch (DCON MS)

1/8

Connection diameter - inch (DCON MS)

0.125

Connection diameter - millimeter (DCON MS)

3.18

Corner radius - fractional inch (RE)

1/16

Corner radius - inch (RE)

0.063

Cut length

Extra long

Cutting diameter - fractional inch (DC)

1/8

Cutting diameter - inch (DC)

0.125

Cutting diameter - millimeter (DC)

3.18

Cutting diameter tolerance class (TCDC)

ANSI +.000/-.002

Depth of cut maximum - fractional inch (APMX)

1

EDP number

7648901

Flute count (NOF)

4

Flute helix angle (FHA)

30

Material

HM

Material application

K - Cast iron, M - Stainless steel, P - Steel and cast steel

MID number

7648901

Mill Profile

N - General Purpose Cutter Type for Low to High Resistance Materials

Ordering code ANSI

S2471/8

Overall length - fractional inch (OAL)

3"

Overall length - inch (OAL)

3

Overall length - millimeter (OAL)

76.2

Radial rake angle (GAMF)

10

Shank

Cylindrical shank
