Dormer S5338.0 6706548 square end mill, 8mm cutting diameter, 2-flute, solid carbide (HM), 30° helix angle, -10° radial rake, 12mm max depth of cut, 8mm shank with h6 tolerance, for hardened materials (H). DORMER standard.

Basic Standard

DORMER

Coating

TiSiN

Coating property (CTP)

1

Connection diameter - inch (DCON MS)

0.315

Connection diameter - millimeter (DCON MS)

8

Connection diameter tolerance machine side (TCDCONMS)

h6

Corner radius - inch (RE)

0.1575

Corner radius - millimeter (RE)

4

Cut length

Extra short

Cutting diameter - inch (DC)

0.315

Cutting diameter - millimeter (DC)

8

Cutting diameter tolerance class (TCDC)

h9

Depth of cut maximum - inch (APMX)

0.4724

Depth of cut maximum - millimeter (APMX)

12

EDP number

46706548

Flute count (NOF)

2

Flute helix angle (FHA)

30

Material

HM

Material application

H - Hardened materials

MID number

6706548

Mill Profile

N - General Purpose Cutter Type for Low to High Resistance Materials

Neck diameter - inch (DN)

0.2913

Neck diameter - millimeter (DN)

7.4

Ordering code ANSI

S5338.0

Overall length - inch (OAL)

3.937

Overall length - millimeter (OAL)

100

Peripheral effective cutting edge count (ZEFP)

2

Radial rake angle (GAMF)

-10

Shank

Cylindrical shank DIN 6535 HA

Usable Length - millimeter (LU)

60
