Dormer S53414.0 6706582 square end mill, 14mm cutting diameter, 4-flute, solid carbide (HM), 30° helix angle, -10° radial rake, 32mm max depth of cut, 14mm shank with h6 tolerance. Designed for hardened materials (H application group) with coating for enhanced wear resistance. DORMER standard.

Basic Standard

DORMER

Coating

TiSiN

Coating property (CTP)

1

Connection diameter - inch (DCON MS)

0.5512

Connection diameter - millimeter (DCON MS)

14

Connection diameter tolerance machine side (TCDCONMS)

h6

Corner radius - inch (RE)

0.2756

Corner radius - millimeter (RE)

7

Cut length

Extra short

Cutting diameter - inch (DC)

0.5512

Cutting diameter - millimeter (DC)

14

Cutting diameter tolerance class (TCDC)

h9

Depth of cut maximum - inch (APMX)

1.2598

Depth of cut maximum - millimeter (APMX)

32

EDP number

46706582

Flute count (NOF)

4

Flute helix angle (FHA)

30

Material

HM

Material application

H - Hardened materials

MID number

6706582

Mill Profile

N - General Purpose Cutter Type for Low to High Resistance Materials

Neck diameter - inch (DN)

0.5118

Neck diameter - millimeter (DN)

13

Ordering code ANSI

S53414.0

Overall length - inch (OAL)

3.5433

Overall length - millimeter (OAL)

90

Peripheral effective cutting edge count (ZEFP)

4

Radial rake angle (GAMF)

-10

Shank

Cylindrical shank DIN 6535 HA

Usable Length - millimeter (LU)

44
