5982851

Image for Illustration purposes only. Actual product may vary

Dormer S9337.0 5982851 End Mill 7.00 mm

MODEL 5982851

SKU

6079284

WEIGHT

0.095 lb

UOM

each

$61.21 Each

Prices are subject to change

FREE SHIPPING ON ORDERS OVER $100

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Basic Standard

DORMER

Coating

TiAlN

Coating property (CTP)

1

Connection diameter - inch (DCON MS)

0.315

Connection diameter - millimeter (DCON MS)

8

Corner chamfer width - millimeter (CHW)

0.13

Cut length

Medium

Cutting diameter - inch (DC)

0.2756

Cutting diameter - millimeter (DC)

7

Cutting diameter tolerance class (TCDC)

h10

Depth of cut maximum - inch (APMX)

0.748

Depth of cut maximum - millimeter (APMX)

19

EDP number

40126

Flute count (NOF)

3

Flute helix angle (FHA)

30

Material

HM

Material application

K - Cast iron, N - Non-ferrous metals, P - Steel and cast steel, S - High-temperature alloys

MID number

5982851

Mill Profile

N - General Purpose Cutter Type for Low to High Resistance Materials

Ordering code ANSI

S9337.0

Overall length - inch (OAL)

2.4803

Overall length - millimeter (OAL)

63

Peripheral effective cutting edge count (ZEFP)

3

Radial rake angle (GAMF)

12

Shank

Cylindrical shank DIN 6535 HB

Part of Dormer’s great range of carbide milling cutters, S933 3-flute cutters are a good economical choice for general milling of slots on most types of machine and can be used for plunging, ramping and profile milling in stainless steels, steels and cast iron.

With a medium length flute design, the extra rigidity provided makes them great for milling standard slots and profiling.

S933 3-flute slot drills are manufactured from premium carbide for superior performance and longer tool life, whilst the titanium aluminium nitride coating further increases tool life and improves performance when milling materials which are difficult to machine
