Dormer E5315/8NO3 5977377 machine tap with straight flute, 4 flutes, 5/8" x 11 BSW thread, HSS, ISO 529. For non-ferrous metals and steel/cast steel. Overall length 102mm, connection diameter 12.5mm, pre-drill hole 13.5mm.

Basic Standard

ISO 529

Clamping width - fractional inch (WSC)

10

Clamping width - inch

0.3937

Coating

Bright

Connection diameter - inch (DCON MS)

0.4921

Connection diameter - millimeter (DCON MS)

12.5

Coolant supply property (CSP)

15.875

EDP number

98813

Flute count (NOF)

4

Flute Geometry (FDC)

Straight Flute Geometry

Hand (Cutting direction)

Right

Material

HSS

Material application

N - Non-ferrous metals, P - Steel and cast steel

MID number

5977377

Ordering code ANSI

E5315/8NO3

Overall length - inch (OAL)

4.0157

Overall length - millimeter (OAL)

102

Premachined hole diameter - inch (PHD)

0.5315

Premachined hole diameter - millimeter (PHD)

13.5

Shank

Cylindrical shank with Square

Thread diameter - inch (TD)

0.625

Thread diameter - millimeter (TD)

15.875

Thread diameter size (TDZ)

5/8

Thread form (THFT)

BSW - British standard Whitworth

Threading length - inch (THL)

0.9449

Threading length - millimeter (THL)

24

Threads per inch (TPI)

11

Usable length (ULDR)

1.5
