Dormer E000TINM4 6196636 spiral point machine tap with M4x0.70 thread, 3 flutes, and powder metallurgy cobalt HSS (HSS-E-PM) construction. ISO 529 standard for through-hole threading in stainless steel, non-ferrous metals, and steel. Pre-drill hole diameter 3.3 mm.

Basic Standard

ISO 529

Clamping Length - millimeter (LSC)

6

Clamping width - fractional inch (WSC)

3.15

Clamping width - inch

0.124

Coating

TiN

Coating property (CTP)

1

Connection diameter - inch (DCON MS)

4

EDP number

46196636

Flute count (NOF)

3

Flute Geometry (FDC)

Spiral Point Geometry

Hand (Cutting direction)

Right

Material

HSS-E-PM

Material application

M - Stainless steel, N - Non-ferrous metals, P - Steel and cast steel

MID number

6196636

Ordering code ANSI

E000TINM4

Overall length - inch (OAL)

2.0866

Overall length - millimeter (OAL)

53

Premachined hole diameter - inch (PHD)

0.1299

Premachined hole diameter - millimeter (PHD)

3.3

Shank

Cylindrical shank with Square

Tap chamfer style (TCS)

B 3.5 - 5

Thread diameter size (TDZ)

4

Thread form (THFT)

M - Metric coarse

Thread pitch - inch (TP)

0.0276

Thread pitch - millimeter (TP)

0.7

Threading length - inch (THL)

0.6693

Threading length - millimeter (THL)

17

Tolerance limit

D4

Usable length (ULDR)

2.5

Usable Length - inch (LU)

0.6693

Usable Length - millimeter (LU)

17
