Dormer E005M12 5974426 spiral point machine tap, M12x1.75 thread, powder metallurgy cobalt HSS (HSS-E-PM), 2-flute, ANSI standard. Pre-drill hole diameter 10.3 mm. For non-ferrous metals and steel/cast steel. Overall length 0.367 mm.

Basic Standard

ANSI

Clamping width - inch

0.275

Coating

Bright

Connection diameter - inch (DCON MS)

0.367

Connection diameter - millimeter (DCON MS)

9.32

EDP number

580400

Flute count (NOF)

2

Flute Geometry (FDC)

Spiral Point Geometry

Hand (Cutting direction)

Right

Material

HSS-E-PM

Material application

N - Non-ferrous metals, P - Steel and cast steel

MID number

5974426

Ordering code ANSI

E005M12

Overall length - fractional inch (OAL)

3.3/8

Overall length - inch (OAL)

3.375

Overall length - millimeter (OAL)

85.7

Premachined hole diameter - imperial (PHD)

Y

Premachined hole diameter - inch (PHD)

0.4055

Premachined hole diameter - millimeter (PHD)

10.3

Shank

Cylindrical shank with Square

Tap chamfer style (TCS)

B 3.5 - 5

Thread diameter - millimeter (TD)

Y

Thread diameter size (TDZ)

12

Thread form (THFT)

M - Metric coarse

Thread pitch - inch (TP)

0.0689

Thread pitch - millimeter (TP)

1.75

Threading length - inch (THL)

0.9055

Tolerance limit

D6

Usable length (ULDR)

2.5
