Dormer E006M4 5973941 spiral point machine tap, M4x0.70 thread, powder metallurgy cobalt HSS (HSS-E-PM), 2-flute, ANSI standard. For P - Steel and cast steel applications. Pre-drill hole diameter 3.3 mm.

Basic Standard

ANSI

Clamping width - inch

0.131

Coating

Steam Tempered

Connection diameter - inch (DCON MS)

0.168

Connection diameter - millimeter (DCON MS)

4.27

EDP number

580462

Flute count (NOF)

2

Flute Geometry (FDC)

Spiral Point Geometry

Hand (Cutting direction)

Right

Material

HSS-E-PM

Material application

P - Steel and cast steel

MID number

5973941

Ordering code ANSI

E006M4

Overall length - fractional inch (OAL)

2.1/8

Overall length - inch (OAL)

2.125

Overall length - millimeter (OAL)

0.168

Premachined hole diameter - imperial (PHD)

N30

Premachined hole diameter - inch (PHD)

0.1299

Premachined hole diameter - millimeter (PHD)

3.3

Shank

Cylindrical shank with Square

Tap chamfer style (TCS)

B 3.5 - 5

Thread diameter - millimeter (TD)

N30

Thread diameter size (TDZ)

4

Thread form (THFT)

M - Metric coarse

Thread pitch - inch (TP)

0.0276

Thread pitch - millimeter (TP)

0.7

Threading length - inch (THL)

0.2484

Tolerance limit

D4

Usable length (ULDR)

2.5

Usable Length - inch (LU)

0.6526
