Dormer E007M16 5973791 spiral flute machine tap, M16x2.00 thread, 45° helix, powder metallurgy cobalt HSS (HSS-E-PM), 3 flutes, ANSI standard. For non-ferrous metals, steel, and cast steel. Pre-drill hole diameter 14 mm.

Basic Standard

ANSI

Clamping width - inch

0.36

Coating

Bright

Connection diameter - inch (DCON MS)

0.48

Connection diameter - millimeter (DCON MS)

12.19

Coolant supply property (CSP)

35/64

EDP number

580677

Flute count (NOF)

3

Flute Geometry (FDC)

Spiral Flute Geometry

Flute helix angle (FHA)

45

Hand (Cutting direction)

Right

Material

HSS-E-PM

Material application

N - Non-ferrous metals, P - Steel and cast steel

MID number

5973791

Ordering code ANSI

E007M16

Overall length - fractional inch (OAL)

3.13/16

Overall length - inch (OAL)

3.8125

Overall length - millimeter (OAL)

96.8

Premachined hole diameter - imperial (PHD)

35/64

Premachined hole diameter - inch (PHD)

0.5512

Premachined hole diameter - millimeter (PHD)

45

Shank

Cylindrical shank with Square

Tap chamfer style (TCS)

C 2 - 3

Thread diameter - millimeter (TD)

14

Thread diameter size (TDZ)

16

Thread form (THFT)

M - Metric coarse

Thread pitch - inch (TP)

0.0787

Thread pitch - millimeter (TP)

2

Threading length - inch (THL)

0.7087

Tolerance limit

D7

Usable length (ULDR)

2.5
