Dormer E007M5 5973805 machine tap with spiral flute 45° for M5 x 0.80 mm threads, 3-flute, powder metallurgy cobalt HSS (HSS-E-PM), ANSI standard. Suitable for non-ferrous metals and steel/cast steel. Coolant-through capability.

Basic Standard

ANSI

Clamping width - inch

0.152

Coating

Bright

Connection diameter - inch (DCON MS)

0.194

Connection diameter - millimeter (DCON MS)

4.93

Coolant supply property (CSP)

N19

EDP number

580615

Flute count (NOF)

3

Flute Geometry (FDC)

Spiral Flute Geometry

Flute helix angle (FHA)

45

Hand (Cutting direction)

Right

Material

HSS-E-PM

Material application

N - Non-ferrous metals, P - Steel and cast steel

MID number

5973805

Ordering code ANSI

E007M5

Overall length - fractional inch (OAL)

2.3/8

Overall length - inch (OAL)

2.375

Overall length - millimeter (OAL)

60.3

Premachined hole diameter - imperial (PHD)

N19

Premachined hole diameter - inch (PHD)

0.1654

Premachined hole diameter - millimeter (PHD)

45

Shank

Cylindrical shank with Square

Tap chamfer style (TCS)

C 2 - 3

Thread diameter - millimeter (TD)

4.2

Thread diameter size (TDZ)

5

Thread form (THFT)

M - Metric coarse

Thread pitch - inch (TP)

0.0315

Thread pitch - millimeter (TP)

0.8

Threading length - inch (THL)

0.265

Tolerance limit

D4

Usable length (ULDR)

2.5

Usable Length - inch (LU)

0.8434
