Dormer E8127/8H6 7350352 Machine Tap Blue Shark for Stainless Steel Spiral Flute 4FL 7/8 inch x 9
MODEL 7350352
$196.80 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable:No
California Prop 65 warningBasic Standard
DIN/ANSI
Clamping width - inch
0.52
Coating
SUPER-B
Coating property (CTP)
1
Connection diameter - inch (DCON MS)
0.697
Connection diameter - millimeter (DCON MS)
17.7
Coolant supply property (CSP)
49/64
EDP number
7350352
Flute count (NOF)
4
Flute Geometry (FDC)
Spiral Flute Geometry
Flute helix angle (FHA)
40
Hand (Cutting direction)
Right
Material
HSS-E-PM
Material application
M - Stainless steel
MID number
7350352
Ordering code ANSI
E8127/8H6
Overall length - inch (OAL)
5.512
Overall length - millimeter (OAL)
0.697
Premachined hole diameter - imperial (PHD)
49/64
Premachined hole diameter - inch (PHD)
0.7677
Premachined hole diameter - millimeter (PHD)
40
Shank
Cylindrical shank with Square
Tap chamfer style (TCS)
C 2 - 3
Thread diameter - millimeter (TD)
19.5
Thread diameter size (TDZ)
7/8
Thread form (THFT)
UNC - Unified Coarse
Threading length - inch (THL)
0.984
Threads per inch (TPI)
9
Tolerance limit
H6
Usable length (ULDR)
2.5
Spiral flute tap Blue Shark with chamfer form C with a 2-3xP semi-bottoming lead, for Unified National Coarse thread UNC 7/8" with 9 TPI and 2B class of fit with H6 pitch diameter limits, dimensions according to DIN/ANSI standard with 0.6970" shank and 0.5200" square drive, powder metallurgical HSS-E with Super-B coating and 40° helix angle for 2.5xD blind hole threading in stainless steel.
