5977757

Image for Illustration purposes only. Actual product may vary

View in markdown

Dormer F1801/2 5977757 NPT gun nosed threading die, 1/2" x 14 TPI, High Speed Steel (HSS), ISO 2568. 45mm body diameter, 18mm overall length, 1.75 die chamfer to pitch ratio. For K (cast iron), M (stainless steel), N (non-ferrous metals), and P (steel and cast steel) materials.

MODEL 5977757

BRAND

Dormer Pramet

SKU

6083008

WEIGHT

0.309 lb

UOM

each

$194.80 Each

Prices are subject to change

FREE SHIPPING ON ORDERS OVER $100

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Returnable: Yes

Basic Standard

ISO 2568

Body diameter - inch (BD)

1.7717

Body diameter - millimeter (BD)

45

Coating

Bright

Die chamfer to pitch ratio (DCPR)

1.75

EDP number

161616

Hand (Cutting direction)

Right

Material

HSS

Material application

K - Cast iron, M - Stainless steel, N - Non-ferrous metals, P - Steel and cast steel

MID number

5977757

Ordering code ANSI

F1801/2

Overall length - inch (OAL)

0.7087

Overall length - millimeter (OAL)

18

Thread diameter - millimeter (TD)

19.77

Thread diameter size (TDZ)

1/2

Thread form (THFT)

NPT - National taper pipe

Threads per inch (TPI)

14

Solid round die with a gun nose, for National Pipe Taper thread NPT 1/2" with 14 TPI and normal class of fit, dimensions according to ISO 2568 standard with 45mm outside diameter and 18mm thickness, HSS with lapped surface finish for threading in free machining and plain carbon steel, ferritic stainless steel and gray, malleable, ductile and compacted graphite cast-iron.

When will I be charged for my order? Ordering Do you provide credit terms? Ordering Can I get a discounted price? I am a reseller / government entity. Ordering What is the return/warranty policy? Ordering Can it be shipped today? Ordering Does “Usually ships in 24 hours” mean it’s in stock? Ordering Read full FAQ All FAQs
5.0 out of 5 · 3 reviews

Excelente tiempo de entrega

Verified · SKU 6080992

Rapido tiempo de entrega Read more

Herramientas dormer

Verified · SKU 6075840

EXCELENTE PROVEEDOR ME GUSTA SU ATENCION Y PRESENTAN EXCELENTES PRECIOS Read more

End mill dormer hss

Verified · SKU 6077311

Excelente herramienta de mecanizado , buena calidad para corte de acero inoxidables y al carbono Read more

Catalog PDF
Line Drawing PNG
