Dormer F2721 5978700 G (BSP) die nut, 1 inch diameter with 11 threads per inch, conforming to DIN 382. Designed for cutting British Standard Pipe threads in cast iron, stainless steel, non-ferrous metals, and steel. Suitable for maintenance and threading applications requiring parallel pipe threads.

Basic Standard

DIN 382

Coating

Bright

Die chamfer to pitch ratio (DCPR)

1.75

Drive size - inch (DRVS)

2.3622

Drive size - millimeter (DRVS)

60

EDP number

217375

Hand (Cutting direction)

Right

Material application

K - Cast iron, M - Stainless steel, N - Non-ferrous metals, P - Steel and cast steel

Material code (BMC)

HSS

MID number

5978700

Ordering code ANSI

F2721

Overall length - inch (OAL)

0.7087

Overall length - millimeter (OAL)

18

Thread diameter - millimeter (TD)

33.25

Thread diameter size (TDZ)

1"

Thread form (THFT)

G - British standard pipe fastening - G series

Threads per inch (TPI)

11
