Dormer F2721.1/2 5978702 G(BSP) dienut threading die, DIN 382, 1.1/2 inch diameter x 11 threads per inch. Suitable for K (cast iron), M (stainless steel), N (non-ferrous metals), and P (steel and cast steel) material applications.

Name: Dormer F2721.1/2 5978702 G(BSP) dienut threading die, DIN 382, 1.1/2 inch diameter x 11 threads per inch. Suitable for K (cast iron), M (stainless ste
Brand: Dormer Pramet
Price: 672.67 USD
Availability: InStock
Rating: 5.0 (3 reviews)

MODEL 5978702

BRAND

Dormer Pramet

SKU

6083050

WEIGHT

0.750 lb

UOM

each

$672.67 Each

Prices are subject to change

FREE SHIPPING ON ORDERS OVER $100

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Returnable: Yes

Basic Standard

DIN 382

Coating

Bright

Die chamfer to pitch ratio (DCPR)

1.75

Drive size - inch (DRVS)

3.3465

Drive size - millimeter (DRVS)

EDP number

217382

Hand (Cutting direction)

Right

Material application

K - Cast iron, M - Stainless steel, N - Non-ferrous metals, P - Steel and cast steel

Material code (BMC)

HSS

MID number

5978702

Ordering code ANSI

F2721.1/2

Overall length - inch (OAL)

0.8661

Overall length - millimeter (OAL)

Thread diameter - millimeter (TD)

47.8

Thread diameter size (TDZ)

1.1/2

Thread form (THFT)

G - British standard pipe fastening - G series

Threads per inch (TPI)

Hexagon die nut, for British Standard Pipe thread G 1.1/2" with 11 TPI and class A tolerance, dimensions according to DIN 382 standard with 85mm width across flat and 22mm thickness, HSS with bright finish for repairing damaged thread in free machining and plain carbon steel, ferritic stainless steel and gray, malleable, ductile and compacted graphite cast-iron.
