Dormer Pramet P8443.0X3.0 7059575 rotary burr, 3.00mm cutting diameter, diamond cut router style with end mill cut geometry. Solid carbide construction for non-ferrous metals. 3mm connection diameter with h6 tolerance. 180° point angle. DORMER standard.

ApplicationAngleIcon_DICT_SEL

Drill point 180°

Basic Standard

DORMER

Burr Type Code (BTC)

Fibreglass and Composite Materials Cut Geometry

BurrEndShot_DICT_SEL

End Mill Burr End

Coating

Bright

Connection diameter - inch (DCON MS)

0.1181

Connection diameter - millimeter (DCON MS)

3

Connection diameter tolerance machine side (TCDCONMS)

h6

Cutting diameter - inch (DC)

0.1181

Cutting diameter - millimeter (DC)

3

EDP number

47059575

Material

HM

Material application

N - Non-ferrous metals

MID number

7059575

Ordering code ANSI

P8443.0X3.0

Overall length - inch (OAL)

1.7717

Overall length - millimeter (OAL)

45

Point Angle (SIG)

180

Shank

Cylindrical shank

Usable Length - millimeter (LU)

13
