Dormer H851222.0 7833372 Hydra Body taper reamer, 25mm cutting diameter, 12xD length-to-depth ratio, 343mm overall length, 264mm usable length, 56mm shank length. High Speed Steel (HSS) construction with Bright Silver finish, right-hand cutting direction, h6 shank tolerance, and coolant-through capability. Designed for precision taper reaming applications.

MODEL 7833372

BRAND

SKU

6084380

WEIGHT

1.867 lb

UOM

each

$2,404.28 Each

Prices are subject to change

FREE SHIPPING ON ORDERS OVER $100

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Returnable: Yes

Basic Standard

DORMER

Coating

Nickel Plated

Connection diameter - inch (DCON MS)

0.9843

Connection diameter tolerance machine side (TCDCONMS)

h6

Coolant supply property (CSP)

1

Drill Diameter - mm

25

EDP number

7833372

Hand (Cutting direction)

Right

Length to Depth Ratio

12

Material

HSS

MID number

7833372

Ordering code ANSI

H851222.0

Overall length - inch (OAL)

13.5039

Overall length - mm

343

Shank

Hydra shank - Cylindrical

Shank length - inch (LS)

2.2047

Shank length - millimeter (LS)

56

Surface color

Bright Silver

Usable length (ULDR)

12

Usable Length - inch (LU)

10.3937

Usable Length - mm

264

DOR Replaceable head drill body HYDRA with cylindrical shank with flange, size 22.0mm with an overall length of 343mm and flute length of 264mm according to DORMER standard for 12xD drilling with HYDRA P (R950), HYDRA M (R960) or HYDRA K (R970) diameter 21.83 up to 22.7mm

When will I be charged for my order? Ordering Do you provide credit terms? Ordering Can I get a discounted price? I am a reseller / government entity. Ordering What is the return/warranty policy? Ordering Can it be shipped today? Ordering Does “Usually ships in 24 hours” mean it’s in stock? Ordering Read full FAQ All FAQs

5.0 out of 5 · 3 reviews

End mill dormer hss

Verified · SKU 6077311

Excelente herramienta de mecanizado , buena calidad para corte de acero inoxidables y al carbono Read more

Excelente tiempo de entrega

Verified · SKU 6080992

Rapido tiempo de entrega Read more

Herramientas dormer

Verified · SKU 6075840

EXCELENTE PROVEEDOR ME GUSTA SU ATENCION Y PRESENTAN EXCELENTES PRECIOS Read more

Line Drawing PNG
