5987965

Image for Illustration purposes only. Actual product may vary

View in markdown

Dormer H8531.1/64 5987965 replaceable drill head body, 1/64" diameter, short length, 3xD depth ratio, coolant-through design. High Speed Steel (HSS) construction with bright silver finish, right-hand cutting direction, h6 shank tolerance. 170mm overall length, 88mm usable length, 60mm shank length.

MODEL 5987965

BRAND

SKU

6084403

WEIGHT

1.720 lb

UOM

each

$693.32 Each

Prices are subject to change

FREE SHIPPING ON ORDERS OVER $100

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Returnable: Yes

Basic Standard

DORMER

Coating

Nickel Plated

Connection diameter - inch (DCON MS)

1.25

Connection diameter tolerance machine side (TCDCONMS)

h6

Coolant supply property (CSP)

1

Drill Diameter - fractional inch

1.1/4

Drill Diameter - mm

31.75

Drill Length

Short

EDP number

33180

Hand (Cutting direction)

Right

Length to Depth Ratio

3

Material

HSS

MID number

5987965

Ordering code ANSI

H8531.1/64

Overall length - inch (OAL)

6.6929

Overall length - mm

170

Shank

Cylindrical shank DIN 6535 HE / HB

Shank length - inch (LS)

2.3622

Shank length - millimeter (LS)

60

Surface color

Bright Silver

Usable length (ULDR)

3

Usable Length - inch (LU)

3.4646

Usable Length - mm

88

H853 Hydra drill bodies with coolant feed are short drill bodies designed to fit to R950, R960 and R970 Hydra drill heads.

Tooling needs can be greatly reduced as several different head diameters will fit onto one body, whilst the common shank size gives you the option of versatile tool holding.

Removing one drill head and installing another is quick and easy, and can be done without removing the body from the machine.

The internal coolant holes align perfectly with the interchangeable drill heads for efficient cooling, no matter the head diameter.

H853 Hydra drill bodies are of high quality and will give consistent performance even after many head changes

When will I be charged for my order? Ordering Do you provide credit terms? Ordering Can I get a discounted price? I am a reseller / government entity. Ordering What is the return/warranty policy? Ordering Can it be shipped today? Ordering Does “Usually ships in 24 hours” mean it’s in stock? Ordering Read full FAQ All FAQs

5.0 out of 5 · 3 reviews

End mill dormer hss

Verified · SKU 6077311

Excelente herramienta de mecanizado , buena calidad para corte de acero inoxidables y al carbono Read more

Excelente tiempo de entrega

Verified · SKU 6080992

Rapido tiempo de entrega Read more

Herramientas dormer

Verified · SKU 6075840

EXCELENTE PROVEEDOR ME GUSTA SU ATENCION Y PRESENTAN EXCELENTES PRECIOS Read more

Line Drawing PNG
