Image for Illustration purposes only. Actual product may vary

15007/8X9H4NO1 6007492 Hand Tap UNC 7/8 inch x 9

Name: 15007/8X9H4NO1 6007492 Hand Tap UNC 7/8 inch x 9
Brand: Union Butterfield
Availability: Discontinued

MODEL 6007492

BRAND

Union Butterfield

SKU

6090440

WEIGHT

0.417 lb

UOM

each

Obsolete

This item is no longer available on MROSupply.com, however we have this identical replacement.

Dormer E0617/8NO1 5974310 Hand Tap Straight Flute UNC 7/8 inch x 9

$56.85 Each

View Replacement

Typically Ships in: 1 day

Returnable: Yes

Basic Standard

ANSI

Clamping width - inch

0.523

Coating

Bright

Connection diameter - inch (DCON MS)

0.697

Connection diameter - millimeter (DCON MS)

17.7

Flute count (NOF)

Flute Geometry (FDC)

Straight Flute Geometry

Hand (Cutting direction)

Right

Material

HSS

Overall length - fractional inch (OAL)

4.11/16

Overall length - inch (OAL)

4.6875

Shank

Cylindrical shank with Square

Thread diameter size (TDZ)

7/8

Thread form (THFT)

UNC - Unified Coarse

Threading length - fractional inch (THL)

2.7/32

Threads per inch (TPI)

Tolerance limit

Usable length (ULDR)

1.5

The 1500 series of Union Butterfield hand taps are the most versatile taps for hand use or machine tapping. They are manufactured conforming to the American National Standards Institute (ANSI) and can be used in many materials including steel, cast iron, aluminum and stainless steel, making them a very versatile choice. They come with a bright finish which prevents workpiece material from sticking to the cutting edges so you get cleaner, more accurate threads, and a straight flute design, suitable for threading both through and blind holes.
