Image for Illustration purposes only. Actual product may vary
15191/4X20X6 6006701 UNC Pulley Tap 1/4 inch x 20
MODEL 6006701
$44.31 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
ANSI
Clamping width - inch
0.191
Coating
Bright
Connection diameter - inch (DCON MS)
0.255
Connection diameter - millimeter (DCON MS)
6.48
Flute count (NOF)
4
Flute Geometry (FDC)
Straight Flute Geometry
Hand (Cutting direction)
Right
Material
HSS
Overall length - fractional inch (OAL)
6"
Overall length - inch (OAL)
6
Shank
Cylindrical shank with Square
Tap chamfer style (TCS)
plug chamfer three to six pitch
Thread diameter size (TDZ)
1/4
Thread form (THFT)
UNC - Unified Coarse
Threading length - fractional inch (THL)
1
Threads per inch (TPI)
20
Tolerance limit
H3
Usable length (ULDR)
1.5
Straight flute hand pulley tap with a 3-6xP plug lead, for Unified National Coarse thread UNC 1/4" with 20 TPI and 3B class of fit with H3 pitch diameter limits, dimensions according to ANSI standard with 0.2550" shank and 0.1910" square drive, HSS with bright finish for 1.5xD through or blind hole threading in general purpose applications.
