15288-32H34FLNO1 6007034 Hand Tap UNC No.8 x 32
MODEL 6007034
$4.31 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
ANSI
Clamping width - inch
0.131
Coating
Bright
Connection diameter - inch (DCON MS)
0.168
Connection diameter - millimeter (DCON MS)
4.27
Flute count (NOF)
4
Flute Geometry (FDC)
Straight Flute Geometry
Hand (Cutting direction)
Right
Material
HSS
Overall length - fractional inch (OAL)
2.1/8
Overall length - inch (OAL)
2.125
Shank
Cylindrical shank with Square
Thread diameter size (TDZ)
8
Thread form (THFT)
UNC - Unified Coarse
Threading length - fractional inch (THL)
3/4
Threads per inch (TPI)
32
Tolerance limit
H3
Usable length (ULDR)
1.5
Straight flute hand tap NO1 with a 6-8xP taper lead, for Unified National Coarse thread UNC 8 with 32 TPI and 2B class of fit with H3 pitch diameter limits, dimensions according to ANSI standard with 0.1680" shank and 0.1310" square drive, HSS with bright finish for 1.5xD through or blind hole threading in general purpose applications.
