15441X11.1/2 6007183 NPT Pipe Tap 5FL 1 inch x 11.5

Name: 15441X11.1/2 6007183 NPT Pipe Tap 5FL 1 inch x 11.5
Brand: Union Butterfield
Price: 99.92 USD
Availability: InStock

MODEL 6007183

BRAND

Union Butterfield

SKU

6090841

WEIGHT

0.838 lb

UOM

each

$99.92 Each

Prices are subject to change

ADD $0.08 MORE FOR FREE SHIPPING

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Returnable: Yes

Basic Standard

~ANSI B94.9

Clamping width - inch

0.843

Coating

Nitride

Connection diameter - inch (DCON MS)

1.125

Connection diameter - millimeter (DCON MS)

28.58

Flute count (NOF)

Flute Geometry (FDC)

Straight Flute Geometry

Hand (Cutting direction)

Right

Material

HSS

Overall length - fractional inch (OAL)

3.3/4

Overall length - inch (OAL)

3.75

Shank

Cylindrical shank with Square

Thread diameter size (TDZ)

Thread form (THFT)

NPT - National taper pipe

Threading length - fractional inch (THL)

1.3/4

Threads per inch (TPI)

11.5

Usable length (ULDR)

1.5

Straight flute tap with a 2-3xP semi-bottoming lead, for National Pipe Taper thread NPT 1" with 11.5 TPI and Normal class of fit, dimensions according to ~ANSI B94.9 standard with 1.1250" shank and 0.8430" square drive, HSS with nitride surface finish for 1.5xD through or blind hole threading in alloy steel.
