15883/8X24NO3 6007721 UNF Machine Tap SPRL FL 52D 3/8 inch x 24
MODEL 6007721
$14.96 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
ANSI
Clamping width - inch
0.286
Coating
Bright
Connection diameter - inch (DCON MS)
0.381
Connection diameter - millimeter (DCON MS)
9.68
Flute count (NOF)
3
Flute Geometry (FDC)
Spiral Flute Geometry
Flute helix angle (FHA)
52
Hand (Cutting direction)
Right
Material
HSS
Overall length - millimeter (OAL)
0.381
Overall length - fractional inch (OAL)
2.15/16
Overall length - inch (OAL)
2.9375
Premachined hole diameter - millimeter (PHD)
52
Shank
Cylindrical shank with Square
Thread diameter size (TDZ)
3/8
Thread form (THFT)
UNF - Unified Fine
Threading length - fractional inch (THL)
1.1/4
Threads per inch (TPI)
24
Tolerance limit
H3
Usable length (ULDR)
2.5
Spiral flute tap NO3 with a 2-3xP semi-bottoming lead, for Unified National Fine thread UNF 3/8" with 24 TPI and 3B class of fit with H3 pitch diameter limits, dimensions according to ANSI standard with 0.3810" shank and 0.2860" square drive, HSS with bright finish and 52° helix angle for 2.5xD blind hole threading in wrought or cast aluminium and copper or copper alloys.
