1785NRM10 6008827 Non-Relieved Style Tap 3FL M10 x 1.50 mm
MODEL 6008827
$13.75 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
ANSI
Clamping width - fractional inch (WSC)
7/16
Clamping width - inch
0.286
Coating
Bright
Connection diameter - millimeter (DCON MS)
7/16
Connection diameter - inch (DCON MS)
0.286
Flute count (NOF)
3
Flute Geometry (FDC)
Spiral Point Geometry
Hand (Cutting direction)
Right
Material
HSS
Overall length - millimeter (OAL)
0.286
Overall length - fractional inch (OAL)
2.15/16
Overall length - inch (OAL)
2.9375
Shank
Cylindrical shank with Square
Thread diameter size (TDZ)
10
Thread form (THFT)
M - Metric coarse
Thread pitch - inch (TP)
0.0591
Thread pitch - millimeter (TP)
1.5
Threading length - fractional inch (THL)
1.1/4
Tolerance limit
D6
Usable length (ULDR)
2.5
Spiral point tap with a 3-6xP plug lead, for ISO-Metric thread M10 with 1.50 mm pitch and 6H class of fit with D6 pitch diameter limits, dimensions according to ANSI standard with 0.2860" shank and 0.2860" square drive, HSS with bright finish for 2.5xD through hole threading in general purpose applications.
