Image for Illustration purposes only. Actual product may vary
1788M12X1.75NO3 6008634 Machine Tap SPRL FL 52D M12 x 1.75 mm
MODEL 6008634
$17.88 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
ANSI
Clamping width - inch
0.275
Coating
Bright
Connection diameter - inch (DCON MS)
0.367
Connection diameter - millimeter (DCON MS)
9.32
Flute count (NOF)
3
Flute Geometry (FDC)
Spiral Flute Geometry
Flute helix angle (FHA)
52
Hand (Cutting direction)
Right
Material
HSS
Overall length - millimeter (OAL)
0.367
Overall length - fractional inch (OAL)
3.3/8
Overall length - inch (OAL)
3.375
Premachined hole diameter - millimeter (PHD)
52
Shank
Cylindrical shank with Square
Thread diameter size (TDZ)
M12
Thread form (THFT)
M - Metric coarse
Thread pitch - inch (TP)
0.0689
Thread pitch - millimeter (TP)
1.75
Threading length - fractional inch (THL)
1.21/32
Tolerance limit
D6
Usable length (ULDR)
2.5
Spiral flute tap NO3 with a 2-3xP semi-bottoming lead, for ISO-Metric thread M12 with 1.75 mm pitch and 6H class of fit with D6 pitch diameter limits, dimensions according to ANSI standard with 0.3670" shank and 0.2750" square drive, HSS with bright finish and 52° helix angle for 2.5xD blind hole threading in wrought or cast aluminium and copper or copper alloys.
