Pramet GL4-S32MB 7803248 double-ended parting-off and grooving blade for GL inserts, 4 mm cutting width, 50 mm maximum cutting depth, 32 mm shank height, 150 mm functional length. Spring clamp System X, neutral direction, for parting-off, tube parting-off, and radial grooving in steel, stainless, cast iron, non-ferrous, superalloys, and hardened materials.

Clamping Type Code (MTP)

System X

Cutting depth maximum - inch (CDX)

1.969

Cutting depth maximum - millimeter (CDX)

50

Cutting width - inch (CW)

0.157

Cutting width - millimeter (CW)

4

Direction of tool

Neutral

Functional height - inch (HF)

0.984

Functional height - millimeter (HF)

25

Functional length - inch (LF)

5.906

Functional length - millimeter (LF)

150

Primary use

Finishing

Shank height - inch (H)

1.26

Shank height - millimeter (H)

32
