E2-16DIAC-D

Image for Illustration purposes only. Actual product may vary

View in markdown

Red Lion Sixnet E2-16DIAC-D ETrak2 distributed I/O module with 16 digital inputs for 120VAC signals. Designed for industrial automation and remote monitoring, this modular unit provides reliable input sensing in a compact form factor. Integrates seamlessly with Sixnet control systems for distributed data acquisition.

MODEL E2-16DIAC-D

SKU

1357740

UOM

each

Contact supplier for technical support on: 717 767 6511 x2

Click for 5% off

$1,027.00 Each

Prices are subject to change

FREE SHIPPING ON ORDERS OVER $100

Select Quantity

GET A QUOTE

Typically Ships in: 1 day

Returnable: See conditions

Specifications:

Discrete Input Channels

  • Voltage range E2-16DIAC-D: 60 – 140 VAC
  • Input Polarity: Sourcing
  • Input isolation: 150 Volts (16 channel modules only)
  • Guaranteed ON voltage: 55 VAC
  • Guaranteed OFF voltage: 35 VAC
  • Input resistance: 10 Kohms
  • Input Protection: High Impedance with overvoltage protection
  • Filtered ON/OFF delay: 25 ms (20 Hz. max. counting rate)
  • Fastest response: 25 ms (20 Hz. max. counting rate)

Environmental

  • Operating temperature: -40 to 75°C
  • MTBF: 1, 432, 797 Hours GB @ 40°C per MIL-HNDBK-217F2

​​Configuration

  • Configured using Sixnet I/O Tool Kit
  • Graphical User Interface (GUI)
