Image for Illustration purposes only. Actual product may vary
Pramet TN 11NLA55:T8030 6755527 Threading Insert Internal Partial Profile - 55° Whitworth Thread
MODEL 6755527
This product has a minimum order quantity of (5 minimum) This is the minimum order quantity available when purchasing this product.
$23.34 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity(5 minimum)
Typically Ships in: 1 day
Returnable: Yes
Chipbreaker
No chipbreaker
Coating
T8030
Coating property (CTP)
1
Cutting edge length - inch (L)
0.433
Cutting edge length - millimeter (L)
11
Inscribed circle diameter - inch (IC)
0.25
Inscribed circle diameter - millimeter (IC)
6.35
Insert shape code (SC)
T - triangular 60° included angle
Insert thickness - inch (S)
0.118
Insert thickness - millimeter (S)
3
Package Quantity
5
Profile distance ex - inch (PDX)
0.031
Profile distance ex - millimeter (PDX)
0.8
Profile distance ey - inch (PDY)
0.024
Profile distance ey - millimeter (PDY)
0.6
Thread pitch maximum - inch (TPX)
0.0591
Thread pitch maximum - millimeter (TPX)
1.5
Thread pitch minimum - inch (TPN)
0.0197
Thread pitch minimum - millimeter (TPN)
0.5
Thread type (TTP)
internal
Threads per inch - maximum
48
Threads per inch - minimum
16
Single-sided threading insert, triangular with an inscribed circle diameter of 6.35mm, for left hand cutting partial profile of British Standard internal threads with 48 to 16TPI, T8030 PVD coated fine grained WC-Co carbide within ISO-grade ranges P25-P40/M20-M35 and K20-K40 for machining of steel, stainless-steel and cast-iron
