Dormer Pramet A022.6 (MID 5966732) 0.60mm (0.0236") diameter stub drill bit with 135° point angle, High Speed Steel (HSS), standard spiral flute, 3.5mm flute length, h8 tolerance. Suitable for steel, stainless steel, cast iron, non-ferrous metals, and high-temperature alloys. Conforms to DIN/ANSI standards.
MODEL 5966732
This product has a minimum order quantity of (10 minimum) This is the minimum order quantity available when purchasing this product.
$12.97 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity(10 minimum)
Typically Ships in: 1 day
Returnable: Yes
ApplicationAngleIcon_DICT_SEL
Drill point 135°
Basic Standard
DIN/ANSI
Coating
Bright
Coating property (CTP)
1
Connection diameter - millimeter (DCON MS)
0.6
Cutting diameter - inch (DC)
0.0236
Cutting diameter - millimeter (DC)
0.6
Cutting diameter tolerance class (TCDC)
h8
EDP number
600399
Hand (Cutting direction)
Right
Length chip flute - inch (LCF)
0.1378
Length chip flute - millimeter (LCF)
3.5
Material
HSS
MID number
5966732
Ordering code ANSI
A022.6
Overall length - inch (OAL)
0.8268
Overall length - millimeter (OAL)
21
Point Angle (SIG)
135
Shank
Cylindrical shank
Spiral form
Standard Spiral
Usable length (ULDR)
2.5
A022 stub drills are very versatile and are suitable for a wide variety of hand held and machine applications.
They are manufactured from premium High Speed Steel and can be used for drilling a number of different materials including steels, stainless steels and aluminium.
With a titanium nitride coating, you get better performance when drilling harder materials and a longer tool life.
The specially designed 135 degree split point is a great aid to self-centering when drilling by hand – so no more wandering all over the surface of the workpiece – and you also get a more accurate hole with a better quality of finish.
