Image for Illustration purposes only. Actual product may vary
Dormer A9405.8 5972156 130° PFX Long Series Drill 5.80 mm
MODEL 5972156
$22.68 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningApplicationAngleIcon_DICT_SEL
Drill point 130°
Basic Standard
DIN/ANSI
Coating
Bright
Connection (shank) description
Cylindrical shank
Connection diameter - millimeter (DCON MS)
5.8
Cutting diameter - inch (DC)
0.2283
Cutting diameter - millimeter (DC)
5.8
Cutting diameter tolerance class (TCDC)
h8
Drill Length
Long
EDP number
59227
Hand (Cutting direction)
Right
Length chip flute - inch (LCF)
3.5827
Length chip flute - millimeter (LCF)
91
Material
HSS-E
Material application
M - Stainless steel, N - Non-ferrous metals, P - Steel and cast steel, S - High-temperature alloys
MID number
5972182
Ordering code ANSI
A9405/8
Overall length - inch (OAL)
5.4724
Overall length - millimeter (OAL)
139
Point Angle (SIG)
130
Spiral form
Quick Spiral
Surface treatement
Original surface
Usable length (ULDR)
10
The A940 long series PFX drill from Dormer comes in a range of fractional and metric diameters.
The special parabolic flute design means you can drill extra deep holes in a single pass whilst the 130 degree point angle helps with self-centering - no more wandering over the workpiece surface trying to start the hole - and also reduces the amount of force needed to drill into the workpiece.
The A920 is manufactured from High Speed cobalt so the tool can be used to machine many materials including steels, stainless steels and aluminium, and has a bright finish to stop workpiece material from sticking to the cutting edges of the tool.
The high performance A940 PFX drill is capable of producing high quality and accurate holes (to H10 hole tolerance) even at high speeds and feeds
