Image for Illustration purposes only. Actual product may vary
Dormer C94832.0 5985211 Roughing End Mill 32.00 mm
MODEL 5985211
$583.85 Each
Prices are subject to change
FREE SHIPPING ON ORDERS OVER $100
Select Quantity
Typically Ships in: 1 day
Returnable: Yes
California Prop 65 warningBasic Standard
DIN 844 L
Coating
ALCRONA
Coating property (CTP)
1
Connection diameter - inch (DCON MS)
1.2598
Connection diameter - millimeter (DCON MS)
32
Cut length
Long
Cutting diameter - inch (DC)
1.2598
Cutting diameter - millimeter (DC)
32
Cutting diameter tolerance class (TCDC)
k12
Depth of cut maximum - inch (APMX)
4.1732
Depth of cut maximum - millimeter (APMX)
106
EDP number
128695
Flute count (NOF)
6
Flute helix angle (FHA)
35
Material
HSS-E-PM
MID number
5985211
Mill Profile
NRA - Coarse Pitch Asymmetrical Rounded Profile Chipbreaker
Neck diameter - inch (DN)
1.2402
Neck diameter - millimeter (DN)
31.5
Ordering code ANSI
C94832.0
Overall length - inch (OAL)
7.3228
Overall length - millimeter (OAL)
186
Peripheral effective cutting edge count (ZEFP)
6
Radial rake angle (GAMF)
12
Shank
Weldon shank DIN 1835B
Usable Length - millimeter (LU)
125.5
Dormer’s C948 milling cutters can be used for roughing when plunging, ramping and profile milling in steels, stainless steels and cast iron.
They are manufactured from powder metal High Speed steel for greatly improved performance and extended tool life, whilst the Alcrona coating further increases the service life of the tool and improves performance when milling difficult to machine materials.
C948 roughing cutters have a 35 degree helix which reduces vibration and improves performance when used in CNC machines, whilst the long series flute design with NRA profile is designed to break chips for efficient roughing of deep profiles
